| AREA/ SERVICES | FABRICATION /ASSEMBLY | ERECTION /INSTLLATION | COMMISSIONING |
| Industrial Piping - Alloy Steel Especially P-91, Stainless Steel & Carbon Steel - Ibr & Non Ibr Both | ● | ● | ● |
| Specialised Industrial Piping ( INVAR, INCONEL,DUPLEX, TITANIUM ) | ● | ● | ● |
| Steel Structure | ● | ● | ● |
| Precast ( H-Frame & L-Beam) | ● | ||
| Google Valve & Chute | ● | ||
| Heaters, Heat Exchangers & Reboilers | ● | ||
| Pressured Vessels | ● | ||
| Heavy Equipment (Static & Rotary), Columns & Chimneys | ● | ● | |
| Manpower Supply | ● | ● | ● |
| AREA/ SERVICES | FABRICATION /ASSEMBLY | ERECTION /INSTLLATION | OTHER CRITICAL WORKS |
| Under ground(UG) & Above ground(Ag) Piping | ● | ● | |
| Steel Structure | ● | ● | |
| Equipment | ● | ● | |
| Manpower Supply | ● | ● | ● |
| AREA/ SERVICES | FABRICATION /ASSEMBLY | ERECTION /INSTLLATION | OTHER CRITICAL WORKS |
| Embedded Plate ( Ep) (Carbon Steel & Stainless Steel) | ● | ● | |
| Inner Containtment Wall Liner | ● | ● | |
| Calandria Vault (Stainless Steel) | ● | ● | |
| Preformed Ring Liner & Spider Beam( for Ring Liner Erection) | ● | ● | |
| Annulas Gas Monitoring System ( Profile An Sniffer Tube)Welding With Calendria End Shield | ● | ||
| Steel Structure | ● | ● | |
| Equipment | ● | ||
| Under Ground(UG) & Above Ground(AG) Piping | ● | ● | |
| Dome( Fabrication, Erection ( Single Lift With Sg Opening Approx 328 Mt) And Alignment Jobs. | ● | ● | ● |
| D2O Tower (54 Mtr Ht & 450 Mt Wt) | ● | ||
| Manpower Supply | ● | ● | ● |
| AREA/ SERVICES | FABRICATION /ASSEMBLY | ERECTION /INSTLLATION | COMMISSIONING | OTHER CRITICAL WORKS |
| Hull and Outfitting works | ● | ● | ● | |
| Rotary Equipments | ● | ● | ||
| Piping Jobs | ● | ● | ● | ● |
| Sea Trial | ● | |||
| Manpower Supply | ● | ● | ● | ● |
| LIFTING FRAME (LF) | ||||
| AREA/ SERVICES | FABRICATION /ASSEMBLY | ERECTION /ALLIGNMENT | LOAD TEST | AUTO LAUNCHING |
| Lifting Frame | ● | ● | ● | ● |
| Hydraulic Jacks | ● | ● | ||
| Balance Cantilever Segment | ● | |||
| Simply Supported Span(Iso Span) | ● | |||
| Trestles For Back Span | ● | |||
| Manpower Supply | ● | ● | ● |
| LAUNCHING GIRDER | ||||
| AREA/ SERVICES | FABRICATION /ASSEMBLY | ERECTION /ALLIGNMENT | LOAD TEST | AUTO LAUNCHING |
| Lg Box | ● | ● | ● | ● |
| Lg Supports( Rear , Auxillary, Middle, Front ) | ● | ● | ||
| Segment Trolly For Transferring Segments | ● | |||
| Winch For Segment Erection | ● | |||
| Segment Erection & Alligment | ● | |||
| Manpower Supply | ● | ● | ● | ● |
